ZMP Reverse Camera
This reverse camera integrated with a vehicle specific boot lid handle is a super useful modern driving assist tool that replaces your existing boot handle and provides enhanced visibility and safety in navigating tight parking spots without damaging your car.
This unit has been designed so that it replaces your existing boot handle for easy installation. This means no drilling or modification required to force fitment! The reverse camera is integrated in to the replacement boot lid providing a professional factory / original equipment look as well as a discrete inbuilt camera.
SIZE: 110mm x 48mm
FEATURES:
- Easy installation with no drilling or modification required
- Replaces The Boot Handle
- Built In Rear View Camera
- Provides Parking Guidelines (Aftermarket car head unit or monitor required to show camera display)
- Video Format: NTSC
- Distance Guide Lines
- Wide Angle View
- Waterproof
- High Definition Display
- Includes 6m video cable with trigger line & DC power wiring
To Replace Existing Boot Lid Handles with the OE Reference / Part Numbers.
VW / AUDI:
5N0827566T
5C6827566B
5C6827566D
5C6827566F
IMPORTANT INFORMATION:
IMPORTANT INFORMATION:
The camera is only compatible with an aftermarket car head unit or monitor that will accept this cameras video signal. Your head unit or monitor will also require a CAM-In RCA phono connection. This will NOT work directly with any factory fitted monitors or head units. You will require an interface (if available) adapter for a factory head unit to accept an after-market rear view camera.
PRODUCT SPECIFICATION AND FITMENT
PRODUCT SPECIFICATION AND FITMENT
Image Sensor: Color CCD
Video Format: NTSC/PAL
Resolution: 658 x 462 Pixels/628 x 586 Pixels
Horizontal Resolution： 500TVL
Shutter Speed： 1/60-20us
Minimum Illumination: 0.2Lux/ F1.8=1.2 (0 Lux with Led)
Lens Angle: 170° (diagonal)
White balance： Auto
Color： Black
Waterproof: IP69k
Video Output: 1.0Vp-p, 75ohm
Power Consumption: Max 80mA
Power Supply: DC 12V
Operating Temperature: -20°C~ 60°C, RH95% Max.
Storage Temperature: -30°C ~ 60°C, RH95% Max.
Video Cable Length: 6m
Power Supply Cable Length: 1m
SUITABLE FOR THE FOLLOWING MODELS
SUITABLE FOR THE FOLLOWING MODELS
Audi A3 [8V] (2013-2016)
Audi A4 [B8] (2008-2015)
Audi A5 [8T] (2007-2016)
Audi A6 [MK3 C6/4F] (2004-2011)
Audi A6 [MK4 C7/4G] (2011-2015)
Audi A6 [MK4 Facelift C7] (2015-2018)
Audi A7 [MK1 Type 4G8] (2010-2015)
Audi A7 [MK1 Facelift 4G8] (2015-2018)
Audi Q3 [8U] (2011-2018)
Audi Q5 [8R] (2008-2016)
Audi Q7 [MK1 4L Facelift] (2010-2015)
Audi Q7 [MK2 4M] (2016-2019)
Porsche Cayenne [MK2 958] (2010-2015)
Seat Alhambra [MK2 7N] (2010-2016)
Skoda Octavia [MK3] (2013-2018)
Skoda Superb [B6 Type 3T] (2008-2015)
Skoda Superb [B8] (2015-2019)
Skoda Yeti [Type 5L] (2009-2017)
Volkswagen Golf [Mk6 5K] (2009-2012)
Volkswagen Jetta [MK6] (2010-2018)
Volkswagen Passat B6 (2005-2010)
Volkswagen Passat B7 (2010-2015)
Volkswagen Passat B8 (2015-2019)
Volkswagen Sharan [MK2] (2010-2016)
Volkswagen Tiguan (2008-2016)
Volkswagen Touareg [MK2] (2010-2018)
Volkswagen Touran [MK1 Facelift] (2010-2015)
